Frequency response – 20-20.000 Hz + 2 / – 3 dB
Tracking ability at 315Hz at recommended tracking force *) – 70 µm
Compliance, dynamic, lateral – 25 µm/mN
Stylus type – Nude Elliptical
Stylus tip radius – r/R 8/18 µm
*) Typical value
Tracking force range – 1.25-1.75 g (12.5-17.5 mN)
Tracking force, recommended – 1.5 g (15 mN)
Tracking angle – 20°
Stylus colour – Black
Recommended for Series 520 MkII, 520, 520P
