The slim profile of its Nude Fine Line diamond stylus will track even the highest frequency information, making it a must for discerning listeners.
Additionally its larger footprint ensures reduced distortion and record wear.
The sound will be very evenhanded with respect to all aspects. Classical music will be reproduced with power and open space around each of the instruments.
The ST-7 transformer is a perfect match for the MC Quintet Bronze cartridge.
LH-4000 headshell is specially recommended for MC Quintet cartridges series.
The MC Quintet Series is congruent with Ortofon’s unrelenting commitment to providing the most precise and accurate reproduction possible without coloration:
It is our aim to bring our customers many hours of new and surprising experiences in listening to their precious vinyl collection.
|Output voltage at 1000 Hz, 5cm/sec.||0.3 mV|
|Channel balance at 1 kHz||1.2 dB|
|Channel separation at 1 kHz||23 dB|
|Channel separation at 15 kHz||15 dB|
|Frequency response||20-20.000 Hz – +/-1.5 dB|
|Tracking ability at 315Hz at recommended tracking force||80 µm|
|Compliance, dynamic, lateral||15 µm/mN|
|Stylus type||Nude Fine Line|
|Stylus tip radius||r/R 8/40 µm|
|Tracking force range||2.1-2.5 g (21-25 mN)|
|Tracking force, recommended||2.3 g (23 mN)|
|Internal impedance, DC resistance||5 Ohm|
|Recommended load impedance||20 Ohm|
|Cartridge body material||ABS/Aluminium|
|Coil wire material||Pure 4-nines copper|
|Cartridge weight||9 gram|
